Founction

Recipts & Label print

Printing

Printing method

Thermal dot line printing

Resolution

203dpi, 8dots/mm,576dot

Printing speed

50~80mm/s

Valid printing width

72mm

Interface

Bluetooth (Android + IOS), Type-c

Power saving

Sleep mode

YES

Character Set

Font

ASCII:9×17,12×24; Multiple code pages support

Barcode Symbologies

1D

UPC-A, UPC-E, EAN8, EAN13, CODE39, ITF,

CODEBAR, CODE128, CODE93

2D

QR code

Graphics

Support bitmap printing with different density and user defined bitmap printing (Max. 40K for perbitmap, and Max. 64K for total)

Detection

Sensors

Paper out detection

LED indicator

Power

Power indicator (green)

BT indicator (Blue)

Feed

Charging indicator (yellow)

Error indicator (red)

Charging

Charger

1)     5V/1A in Adapter,

2)     5V/500mA in computer USB connector

Battery

2000mAh/8.4V rechargeable Li-ion battery

Full charge can print 150~200m (printing density not more than 12.5%) or 80~100mm (printing density not more than 25%)

Recommended paper

FD210, PD150R, PD160R

Paper width

80mm

Paper thickness

60～80μm

Paper roller diameter

≤50mm

Paper loading

Easy loading mechanism

Physical characteristics

Working condition

-10°C~50°C , 20%~85%RH

Storage condition

-20°C~70°C, 5%~95%RH

Dimension

122*104*61mm

Weight

350g (without paper roll)

Reliability

TPH

50km (not more than 12.5% printing density)/100

million pulses

Software

Emulation

ESC/POS compatible command set

Driver

Windows XP//Win7/Win8/Win10
