Printing Method

Thermal line

Printing Speed

160mm/s （MAX)

Resolution

8dot/mm，576dot/line

Overall dimensions

132mm W×115mm D×82.95mm H

Effective print width

72mm

Character Set

Western characters: 12×24 dot，1.5（W）×3.00（H）mm
Chinese characters: GB18030 Character set 24×24 dot，3.00（W）×3.00（H）mm

Barcode type

Support UPC-A、UPC-E、EAN-13、EAN-8、CODE39、ITF25、CODABAR、CODE93、CODE128、PDF417、QR Code、DATAMatrix barcode printing

Auto-cutter

Half cut, Full cut optional ((Life 1000000 times))

Interface

Rs-232c serial interface: IDC10 socket, support XON/XOFF and DTR/DSR protocol                 USB interface :PH4 interface
Parallel interface :IDC26 pin socket
Cash box control :DC24V, 1A, 6 lines rj-11 socket.
Bluetooth interface: bluetooth dual mode and bluetooth one drag more

MCBF Reliability (print head life)

30-50km

Power

DC24V plus or minus 10%, 2A, 2114s-02 power socket

Command system

ESC/POS printing commands are compatible with IBM/EPSON ESC/P

Store temperature/humidity

–20～60℃/10～90%RH(Relative humidity)

Working temperature/humidity

–10～50℃/10～80%RH(Relative humidity)

Thickness of the paper

0.06~0.08mm

Paper roll request

Type of thermal paper roll: TF50KS－E（Japan paper co.ltd),AF50KS-E(JUJO THERMAL)                               Paper roll:width :79.5±0.5mm
External diameter: 80mm (max) Inside diameter: 12mm±0.3（min）
Paper thickness: 0.06mm～0.08mm

Weight

400g

Detection function

Abnormal detection: lack of paper detection.
Black calibration position: optional.

Work environment

Operating temperature: 0 ℃ to 50 ℃

Operating relative humidity: 10% ~ 80%

Storage temperature: - 20 ℃ ~ 60 ℃

Storage relative humidity: 10% ~ 90%
